. Manufactured in accordance to BS 5041 Part 1:1987
. The Inlet on the Landing Valve is Screwed Thread
. The Landing Valves are classified under low pressure
. Possible to replace the gland seal when pressure with the valve fully closed
. Disc facing is replaceable type
. All the products are suitable for both on-shore and off-shore applications
. Delivery hose connection and blank cap complying with BS 336:2020 Standard
| Body | Copper Alloy to BS 1400 LG 2 |
|---|---|
| Hand Wheel | Grey Cast Iron to BS EN 1561 |
| Inlet | Screw Thread to BS 21 |
| Outlet | Female Instantaneous to BS 336:2010 |
| Working Pressure | 15 Bar Max |
| Valve Seat Test Pressure | 16.5 Bar |
| Body Seat Test Pressure | 22.5 Bar |
| Nominal Size | 2.5 inch |
